LED Pixelated Set Electrics
PxL8 is a modular LED pixel tool kit. Affordable rental set electrics configured to your production requirements.
Each unit measures 4.5” deep and 2.25” tall. The following lengths are avaiable:
| 3 Meter | 181 LEDs |
| 2 Meter | 121 LEDs |
| 1 Meter | 60 LEDs |
| 96 Inch | 147 LEDs |
| 72 Inch | 110 LEDs |
| 48 Inch | 47 LEDs |
1 Meter Unit With Optional End Cap
Customized, Seamless Lengths
Unit Specs
| Pixel Density | 2 runs in parallel & 60/meter |
| LED Spacing | .66 inches |
| LED Spacing | 16.7 mm |
| LED Protocol | WS2812B |
| Colors | RGBA |
| Wavelength | 623/522/472/592 |
| Pixel Grouping | 2 pixels wide-fixed. Grouped in lengths of pixels as desired. |
| Diffusion | Polar White Lucite |
| Finish | Matte black powdercoat |
| Watts / foot | 7.6 |
| Watts / meter | 25.6 |
| Input Voltage | 90v - 240v |
| Power Connector In | Powercon Blue |
| Power Connector Thru | Powercon Gray |
Continued
| Data Cable Type | CAT5 |
| Data Connector | Ethercon |
| Heat Dissipation | Aluminum heatsink |
| Housing | Carbon Steel |
| Hang Mouting | Rear, threaded 1/2-13 insert, multiple mechanical attachments |
| Floor Mounting | Either end, 3/8-16 threaded end cap |
Pixelator Rack
| Decoding | Enttec Pixelator with ethercon patch bays |
| Network | LAN Required |
| Input Protocols | Artnet, sACN, Kinet |
| Cable Type | CAT5 |
| Connector | Ethercon |
| Fixture Parts | 24 |
| Control Source | LED mapping software, lighting console |
Set Electrics
